Baseline Measurement of the Antenna Array for the Chinese Spectral Radioheliograph in the Centimeter-to-Decameter Wave Range
-
摘要: 日像仪采用综合孔径原理成像,利用不同基线单元的相关输出得到复可见度函数,经过傅里叶变换得到源的亮度分布,基线测量精度是影响成像质量的重要因素。提出了采用大地坐标测量结合观测天文源确定方向基准,进行厘米-分米波射电日像仪天线阵单元天线三维坐标位置测量,获得天线基线矢量的方案,并通过在国家天文台明安图观测站建立相对坐标测控网,对射电日像仪天线阵天线基线进行实测定位,整网平差计算结果表明测量方案合理可行,并满足日像仪基线间距离测量精度的要求和相关成图要求。Abstract: The Chinese Spectral Radioheliograph (CSRH) is a aperture synthesis telescope dedicated to solar observation. Its antenna array is aligned in a shape of triple-spiral arms in an area of about 10 square kilometers. A radioheliograph is a radio-astronomy instrument to obtain solar images in radio bands based on image synthesis. The surface-brightness distribution of the sun is recovered from an ensemble of measurements. The first step of the image recovery process is computing the three-dimensional inverse Fourier transformaion of the correlation outputs of different baselines of the entire radioheliograph antenna array.Here, the high-precision baseline-vector measurement is one of the key factors for imgae recovery with high confidence.In this paper, we propose a measurement method of the CSRH baseline vectors. We first set up a coordinate system with its original reference direction is determined by observing a star (e.g. Polaris). Geodetic surveys and high-precision theodolites are then used to measure the three-dimensional coordinates of all the CSRH antennae in this coordinate system. The triangle-network coordinate system with 31 monitoring points spaced at about 500 meters has now been established at the Mingantu Station of the National Astronomical Observatories where the CSRH is located.On November 2011, we measured with the error compensation the three-dimension baseline vectors in the network coordinates. This results in three-dimensional coordinates of the CSRH antennae with a precision better than 5mm rms. Such a precision meets the requirement of high-quality CSRH imaging. The precision can be improved as more measruements are carried out over time.
-
Keywords:
- Aperture synthesis /
- Geodetic survey /
- Radioheliogragh /
- Baseline
-
-
[1] 颜毅华, 张坚, 黄光力. 厘米-分米波高分辨频谱日像仪——项目建议书[R]. 中国科学院国家天文台, 2003. [2] Yan Yihua, Zhang Jian, Wang Wei, et al. The Chinese spectral radioheliograph-CSRH[J]. Earth Moon Planet, 2009, 104(2):97-100. [3] 姬国枢, 王威, 刘飞, 等. CSRH-I的天线选择[J]. 天文研究与方法——国家天文台台刊, 2009, 6(3):209-214. Ji Guoshu, Wang Wei, Liu Fei, et al. Choices of antennas for the CSRH-I[J]. Astronomical Research & Technology——Publications of National Astronomical Observatories of China, 2009, 6(3):209-214. [4] 陈志军, 颜毅华, 刘玉英, 等. 关于中国厘米-分米波频谱日像仪(CSRH)选址与无线电环境监测[J]. 天文研究与技术——国家天文台台刊, 2006, 3(2):168-175. Chen Zhijun, Yan Yihua, Liu Yuying, et al. Site survey and RFI test for CSRH[J]. Astronomical Research & Technology——Publications of National Astronomical Observatories of China, 2006, 3(2):168-175. [5] 王威, 颜毅华, 张坚, 等. CSRH阵列设计研究及馈源设计的初步考虑[J]. 天文学研究与技术——国家天文台台刊, 2006, 3(2):128-134. Wang Wei, Yan Yihua, Zhang Jian, et al. Array configuration and feed design for CSRH[J]. Astronomical Research & Technology——Publications of National Astronomical Observatories of China, 2006, 3(2):128-134. [6] 王绶琯, 吴盛殷, 崔振兴, 等. 射电天文方法[M]. 北京:科学出版社, 1988:120-137. [7] 魏明智. 密云米波综合孔径系统的误差分析和图像处理[D]. 北京:北京天文台, 1986:18-22. [8] Nakajima H, Nishio M, Enome S, et al. The nobeyama radioheliograph[J]. Proceedings of IEEE, 1994, 82:705-713. [9] Thompson A R, J M Moran, G W Swenson. Interferometry and synthesis in radio astronomy[M]. New York:Wiley, 2001:86-90. [10] 张捍卫, 许厚泽, 王爱生. 天文经纬度和天文方位角测定原理[J]. 测绘科学, 2006, 31(4):157-160. Zhang Hanwei, Xu Houze, Wang Aisheng. The basic principle of mensurating astronomical longitude, latitude and azimuth angle[J]. Science of Surveying and Mapping, 2006, 31(4):157-160.
