A Design of W-band Broadband Ortho-mode Transducer
-
摘要: W波段接收机系统能有效接收多条重要的射电天文分子谱线信息，对于天文观测和科学研究有重要意义。W波段正交模耦合器（Ortho-Mode Transducer，OMT）作为接收机系统实现极化分离的关键器件，其性能对接收机整体性能有重要影响。介绍了一款基于Boifot结构的W波段宽带正交模耦合器，并介绍了正交模耦合器的工作原理和设计流程。仿真结果表明，在70~116 GHz频带内，正交模耦合器相对带宽达到49.4%，回波损耗优于18.7 dB，交叉极化优于55.8 dB，端口隔离度优于54 dB。Abstract: The W-band receiver system can effectively receive many important spectral lines for radio astronomy observations, which is of great significance for astronomical observations and scientific research. As a crucial component of the receiver system, the W-band ortho-mode transducer is important to achieve polarization separation and it has a considerable impact on the overall performance of the receiver system. We design a W-band broadband OMT based on the Boifot junction and introduce the working principle and designing process of OMT. The simulation results show that the relative bandwidth of OMT reaches 49.4%, the return loss is better than 18.7 dB, the cross-polarization is better than 55.8 dB, and the port isolation is better than 54 dB in the 70-116 GHz band.
-
Keywords:
- Ortho-Mode Transducer /
- broadband /
- Boifot junction /
- W-band
-
-
[1] 贾茹, 李斌. 天马望远镜Ka波段宽带圆极化器研制[J]. 天文研究与技术, 2017, 14(4):488-494. JIA R, LI B. Development of Ka-band wideband circular polarizer[J]. Astronomical Research & Technology, 2017, 14(4):488-494.
[2] 陈卯蒸, 宁云炜, 马军. 基于Turnstile结构的超宽带正交模耦合器研究[J]. 无线电工程, 2016, 46(10):54-57. CHEN M Z, NING Y W, MA J. Study of a Turnstile ultra wideband waveguide orthomode transducer[J]. Radio Engineering, 2016, 46(10):54-57.
[3] 王涛, 张文静. 宽带正交模耦合器的设计[J]. 无线电工程, 2013, 43(3):40-43. WANG T, ZHANG W J. Design on wide band orthomode transducer[J]. Radio Engineering, 2013, 43(3):40-43.
[4] BOFIOT A M, LIER E, SCHAUG-PETTERSEN T. Simple and broadband orthomode transducer[J]. IEEE Proceedings- H Microwaves, Antennas and Propagation,1990, 137(6):396-400.
[5] ARAMAKI Y, YONEDA N, MIYAZAKI M, et al. Ultra-thin broadband OMT with turnstile junction[C]//IEEE MTT-S International Microwave Symposium Diges. 2003:47-50.
[6] 王海伦, 李斌. K波段宽带圆极化器设计[J]. 天文研究与技术, 2015, 12(4):455-460. WANG H L, LI B. A design of a K-band circular polarizer[J]. Astronomical Research & Technology, 2015, 12(4):455-460.
[7] UHER J, BORNEMANN J, ROSENBERG U. Waveguide components for antenna feed systems:theory and CAD[M]. Norwood:Artech House, 1993:371-445.
[8] HENKE D, CLAUDE S. Design of a 70-116 GHz W-band turnstile OMT[C]//Proceedings of the 44th European Microwave Conference. 2014.
[9] PISANO G, PIETRANERA L, ISAAK K, et al. A broadband WR10 turnstile junction orthomode transducer[J]. IEEE Microwave and Wireless Components Letters, 2007, 17(4):286-288.
[10] ALVARO G, ASAYAMA S. Double-ridged waveguide orthomode transducer (OMT) for the 67-116-GHz band[J]. Journal of Infrared, Millimeter and Terahertz Waves, 2018, 39(8):727-737.
[11] 顾继慧. 微波技术[M]. 北京:科学出版社, 2007:153-155. GU J H. Microwave technology[M]. Beijing:Science Press, 2007:153-155.
[12] POZARD M. Microwave Engineering[M]. Hoboken:John Wiley & Sons Incorporation, 2011:256-260.
